Soundcraft 2400 square preh pots volume controls

I have finally had a moment to sort out some of these boards, and having spent a day at it I hope I have done this correctly.

These are used pots that have been cleaned and I will in a few days set up a test jig for these.

I may not have all the information correct here and would welcome any comments but this is what I have. These details are for the input PCB

The VR is the variable resistor number on the input PCB , the colour is whats marked on the back of the pot, the series is the manufacturers series number PREH which may also help if you can find the data

VR1 MIC TRIM 10K SINGLE YELLOW SERIES 244 WITH BRACKET CLICK

VR2 LINE TRIM 10K SINGLE BLUE SERIES 230 WITH BRACKET CLICK

VR3 HPF 100K DUAL RED 243 SERIES CLICK

VR4 8/16KHZ 47K SINGLE BLUE 214 SERIES CENTRE DETENT

VR5 10KHZ HI MID 47K SINGLE BLUE 214 SERIES CENTRE DETENT

VR6 15DB +/- H MID 100K DUAL RED 243 SERIES CLICK

VR7 2.4KLZ LOW MID 47K SINGLE BLUE 204 SERIES CENTRE DETENT

VR8 15DB +/- LOW MID 100K DUAL RED 243 SERIES CLICK

VR9 15DB +/- 60HZ LPF 47K SINGLE BLUE 214 SERIES CENTRE DETENT

THERE IS NO VR10

VR11-12-13-14-15-16 AUX 10K RED SINGLE 247 SERIES CLICK

VR17 PAN 4K7 DUAL RED 247 SERIES WITH BRACKET CENTRE DETENT

Pots are guaranteed , if any fail they will replaced

I had an original parts list with their DA000x numbers they  give a bit more date about log and lin etc but not much else.

I have other types in stock that were used on some  really upmarket mixers
